Token Monitor

Account quotas, model usage, sessions, activity heatmaps and trends from your existing Token Monitor Hub, in a native Noctalia panel and bar widget.

Plugin

Field	Value
ID	shangshui0302/token-monitor
Entries	Bar widget: bar; panel: panel; service: service (all under shangshui0302/token-monitor)

Requirements

• Noctalia 5.2.0 or newer (plugin API 32 or newer); tested on Noctalia 5.3.0. Native container tooltips used by this plugin set the minimum API requirement.
• A running Token Monitor Hub. Tested against Token Monitor 0.68.0. In Token Monitor, choose Settings → Sync method → Host hub on this device. The default Local only mode does not expose the HTTP Hub.
• No extra commands or runtime packages. Provider authentication stays in Token Monitor.

Usage

1. In Token Monitor, choose Settings → Sync method → Host hub on this device and keep Token Monitor running. Its Local only mode does not expose the Hub used by this plugin.
2. Enable the plugin in Noctalia and add its Token Monitor bar widget.
3. For a Hub on this same computer, keep the default http://127.0.0.1:17321 address and automatic credential lookup enabled. Open the panel and select Test connection to check both data endpoints.
4. Pin an account in Quotas to keep that account in the bar. Explore Models, Sessions, Activity and Trends, using the time controls.

noctalia msg panel-toggle shangshui0302/token-monitor:panel

Automatic lookup checks Token Monitor's native configuration directory and up to 32 immediate homes under ~/distrobox/; it only sends found secrets to loopback addresses. For another or unusual local path, close the Token Monitor settings editor if it is open, turn on Advanced at the top of Noctalia's settings, then reopen the editor and set Credentials file override in the plugin's native settings list. For a remote Hub, set its URL and use the same steps to set Credentials file override. Use HTTPS and never send a local automatically discovered secret to a remote address. A file override always wins. See the connection guide for exact paths, Host/Hub terminology, credential formats and troubleshooting.

Configure the plugin through Noctalia: use the panel's gear button or open Settings → Plugins → Token Monitor and select its gear. No hand-written plugin JSON or TOML is needed; Noctalia saves these settings. Token Monitor creates credentials.json for its own Hub secret storage when Host mode needs it. That file is credential storage, not plugin configuration. The plugin's snapshot.json and selection.json are internal data in Noctalia's plugin data directory, not settings files to edit.

Settings

Noctalia presents plugin settings in its native flat list. The Connection, Display and Refresh headings below are documentation indexes only; they are not UI tabs or a selector. Most users can leave Noctalia's Advanced switch off. To edit options marked Advanced, close the Token Monitor editor if it is open, turn on Advanced at the top of Noctalia's settings, then reopen the editor.

Connection

Setting	Type	Default	Access	Meaning
hub_url	string	http://127.0.0.1:17321	Regular	HTTP(S) origin of the Hub, without a path, query or embedded credentials
auto_discover_credentials	bool	true	Regular	Find native/local Distrobox credentials for a loopback Hub when no file override is selected
credentials_file	file	empty	Advanced	Explicit file override; required for authenticated remote Hubs or unusual local paths

Display

Setting	Type	Default	Access	Meaning
initial_view	select	quotas	Regular	Initial tab: quotas, models, sessions, activity or trends
bar_provider	select	codex	Regular	Provider shown in the bar; other accounts remain available in the panel
bar_window	select	first	Regular	First, session, weekly, or lowest known remaining percentage; a missing requested kind shows unavailable
bar_style	select	full	Regular	Provider and value, value only, or icon only
percentage_mode	select	remaining	Regular	Display remaining or used quota, with matching labels and meters
show_account_names	bool	true	Regular	Show account/session/project names; disabling also hides session IDs in the UI
panel_density	select	compact	Regular	Compact or comfortable card spacing and window preview length
heatmap_weeks	select	half	Regular	26 calendar weeks; quarter shows 13 weeks with larger cells
usage_period	select	today	Advanced	Producer today, this month or all-time; Sessions retains all-time and shows an unsupported-data notice
history_granularity	select	daily	Advanced	Group activity and trends by day or month
heatmap_metric	select	tokens	Advanced	Initial heatmap measure: tokens, cost or messages
panel_provider	select	all	Advanced	Initial provider filter; the panel also offers filter buttons
accounts_per_page	int	4	Advanced	Number of account cards per page, 1–8
details_per_page	int	6	Advanced	Detail rows per page, 2–10
show_progress	bool	true	Advanced	Show meters for known percentage quotas
show_reset_time	bool	true	Advanced	Show reset countdowns, with local absolute timestamps on hover
show_collection_time	bool	false	Advanced	Show collection age; stale accounts always show it
warning_threshold	int	20	Advanced	Warn when remaining percentage is at or below this value, 0–100
bar_show_icon	bool	true	Advanced	Show the provider icon beside text; shown only when bar style is full or value
bar_account_index	int	1	Advanced	Fallback only when no account is pinned; pin a named account from Quotas for a stable selection

Refresh

Setting	Type	Default	Access	Meaning
auto_refresh	bool	true	Regular	Periodic polling; disabling it keeps the initial read and manual refresh available
refresh_interval_seconds	int	60	Regular	Polling interval, 30–3600 seconds; shown only when automatic refresh is enabled
refresh_on_open	bool	false	Advanced	Request a fresh snapshot when the panel opens

Use the panel gear or Noctalia's plugin settings. The user guide explains display privacy, time periods, missing data, heatmap intensity and quota window selection. Provider marks and licenses cover all 29 quota providers in Token Monitor 0.68.0, plus New API and Sub2API adapters.

Custom native settings sections are not supported. The Hub does not provide all-time session records, transcripts, historical quota snapshots or arbitrary hourly usage breakdowns. When Sessions is set to All time, the panel keeps that selection and shows the unsupported-data notice; choose Today or This month to view the available session summaries. The plugin uses the Hub's documented /api/stats and /api/history routes only.

IPC

# Refresh the shared data snapshot.
noctalia msg plugin shangshui0302/token-monitor:service all refresh
# Open the panel directly on a tab: quotas, models, sessions, activity or trends.
noctalia msg panel-open shangshui0302/token-monitor:panel
noctalia msg plugin shangshui0302/token-monitor:panel all view activity

Notes

• Network: native HTTP GET /api/stats and GET /api/history on the configured Hub, with an optional Bearer secret. Redirects are disabled. The plugin only reads snapshots; freshness depends on Token Monitor's collectors.
• Reads: the configured/discovered credentials file, bundled icon font and its own cache/selection files. No OAuth token discovery or runtime asset downloads.
• Writes: snapshot.json and selection.json in noctalia.pluginDataDir(). The cache contains normalized display data, including account/session labels, source scope and receipt times; it excludes secrets, transcripts and raw payloads. The privacy toggle hides names in the UI, but does not erase the local cache.
• Processes: none. The plugin does not start a shell, browser or Token Monitor.
• Responses are limited to 4 MiB; quota snapshots support 128 accounts, 32 windows per account and 512 windows in total. Oversized snapshots fail explicitly while retaining the previous data. Other displayed detail has explicit size limits. Missing values stay unknown; a successful Hub request does not imply fresh provider collection. API coverage and limitations describe the contract.
• English strings ship in translations/en.json; additional languages use Noctalia Translate's human review/export workflow.

For contributing and repeatable checks, see validation.
