Niri Ribbon

A bar widget for niri's scrollable-tiling layout: it draws the active workspace's whole scrolling ribbon on each monitor as a slim overview strip and highlights the region currently inside the viewport, so you can see at a glance how many columns are hidden to the left and right — and scrolling over the widget moves the focused column.

Plugin

Field	Value
ID	luochen1990/niri-ribbon
Entries	Bar widget: ribbon; shared service: compositor

Requirements

• The niri compositor (declared as the niri dependency; the widget shells out to niri msg).
• Noctalia 5.0.0-beta.4 or newer for the scroll interaction (the onScroll bar-widget API).

Usage

Add the widget via Noctalia Settings → Bar → widgets: pick Niri Ribbon and place it in the start/center/end section. Each instance renders its own monitor's active workspace; the highlighted segment is the current viewport. Estimated viewport positions are remembered separately by workspace ID.

The highlight smoothly animates position and width changes over 200 ms at the default Animation Speed of 1×. Higher speeds are faster; 0 disables animations. Rapid changes continue from the current animated position; the initial state appears immediately.

Scroll up/left or down/right over the widget to run focus-column-left / focus-column-right on niri's currently focused monitor. The widget does not switch monitor focus, avoiding the pointer warp caused by focus-monitor. Each ribbon still displays its own monitor's active workspace.

Enable Show Active Window to mark the active tiled window within the viewport. Active Window Color (default: secondary) sets the solid marker color. The marker follows the window's horizontal tile footprint, animates on focus/size changes, and is clipped to the visible region. Stacked windows share a horizontal footprint; floating windows have no marker.

Settings

Setting	Type	Default	Description
animation_speed	double	1.0	Speed multiplier from 0 to 3; 0 disables animations, 1 is normal, higher is faster.
bar_color	color	outline	Color of the ribbon track (the non-visible area).
viewport_color	color	primary	Color of the viewport highlight.
show_active_window	bool	false	Show the active tiled window inside the viewport with a solid color.
active_window_color	color	secondary	Color of the active-window marker.
thickness	double	4.0	Vertical thickness of the ribbon (logical pixels).
radius	double	2.0	Corner radius of the viewport highlight (logical pixels).
viewport_model	select	fit	How the viewport position is estimated; must match your niri center-focused-column setting: fit for never (niri default), center for always.
gaps	double	0.0	The layout.gaps value from your niri config (logical pixels); used for accurate canvas-width estimation.

Notes

• Viewport position is estimated. Standard niri IPC does not expose the live viewport offset. The fit model remembers the position per workspace, scrolls in either direction to reveal an off-screen focused column, and keeps the position when the focused column is already visible. The initial position, scrolling without a focus change, and custom struts can still differ from niri. Match the viewport model and gaps settings to your niri config. Exact viewport IPC is tracked in niri#4147.
• Resource use: one shared service maintains the compositor cache for all monitors. It applies window/workspace events directly, ignores title and vertical-only changes, and batches changed views over 33 ms. Widgets receive only their monitor’s active workspace geometry and stop animation updates when settled.
• Recovery: one shared snapshot round every 60 seconds covers missed events. Output topology/config changes also refresh output geometry, at most once per second. Failed queries preserve cached data, and older query responses cannot overwrite newer events. A stopped event stream reconnects after two seconds.
• Spawned processes: read-only niri msg IPC queries (windows, workspaces, outputs), one shared niri msg -j event-stream subscription with a reconnecting shell, and focus-column-* actions on scroll. No network access, no filesystem writes.
• Credits: the algorithm idea originates from ews/noctalia-niri-ribbon by J Pablo Puerta (quickshell/QML era); this plugin is a ground-up rewrite for the Noctalia v5 Luau plugin API.
