Network Control

Pick a Wi-Fi network and set how any NetworkManager connection gets its address — DHCP or a static IP, gateway, DNS servers and search domains, IPv4 and IPv6 — from the Noctalia bar. Every write to a connection that is already carrying traffic runs through a confirm window, so a mistyped address cannot leave the machine offline.

Plugin

Field	Value
ID	muhammadessam/network-control
Entries	Bar widget: network; panel: panel; service: service

Requirements

Install nmcli (NetworkManager's command line) on PATH — declared in dependencies together with ip (the default-route lookup) and install/chmod (creating the Wi-Fi passphrase file with mode 0600 before the secret is written into it).

• org.freedesktop.NetworkManager.settings.modify.system must be allowed for the session user — it is on a default install. If it is not, the panel says so and Apply stays disabled instead of failing silently.
• This plugin edits NetworkManager connection profiles only. It does not touch /etc, systemd units or netplan, and it does not manage other backends: systemd-networkd and netplan have no profile API that can be round-tripped safely from a shell plugin.
• Scanning, joining and leaving Wi-Fi needs a working Wi-Fi device; the radio sections stay hidden when there is none.

Usage

Add the network widget to the bar. It shows the name of the network the machine is on, and the glyph changes with the interface type. Click it, or open the panel directly:

noctalia msg panel-toggle muhammadessam/network-control:panel

The panel is three parts, top to bottom.

Route summary — the interface the kernel actually routes through, the connection behind it and its address. No route to the network means there is no default route at all.

Wi-Fi networks (collapsible) — the scan list, strongest first, with a signal glyph, the security type, and saved on networks that already have a profile.

• Scan for networks runs a fresh radio scan; opening the panel reads NetworkManager's cached list first, so opening never blocks on the radio.
• Clicking a network connects to it. An open network or one that is already saved connects in one click; a secured network that is not saved asks for the passphrase inline first.
• Join a hidden network takes an SSID and passphrase for a network that does not broadcast one.
• 802.1X networks are labelled as needing manual setup (identity, certificate, phase-2 method) rather than failing halfway through a join.

Connections and addressing — every editable profile, with the active one marked. Selecting one loads its stored configuration: the IPv4 and IPv6 method, addresses, gateway, DNS servers and search domains. Fields the selected method does not own (addresses while Disabled, for instance) are greyed out and cleared on write, because NetworkManager rejects them outright — and because they are cleared before validation, a half-typed value left in one of them cannot block a write that does not carry it. Below the fields is the exact property diff that Apply will write, then Connect / Disconnect for the selected profile, and a Restore point once a write has happened.

Addresses take a prefix; a bare address gets /24 (IPv4) or /64 (IPv6) rather than the /32 / /128 NetworkManager would otherwise assume.

The confirm window

Applying to an active connection re-activates it and then arms a countdown (confirm_seconds, default 45 s): the panel grows a Keep button, the bar tile turns into a countdown, and if nothing is kept, the saved profile is restored property by property and the connection brought back up.

While a window is open nothing else may change the network: joining a network, bringing a connection up or down, toggling the radio and restoring a backup are all refused by the service and disabled in the panel, because any of them can move the active link before the timer decides what it should be. The window is written to disk with an epoch deadline, so a shell restart inside the window resumes the countdown rather than dropping the promise; if the deadline passed while the shell was down, the rollback happens on the next tick.

With confirm_seconds = 0 there is no window at all: the change is written and the panel says so instead of promising a rollback that will not come.

That window is the point of the plugin. A static address on the interface carrying the default route is the one mistake that takes the machine off the network, and the usual recovery route — a browser, a search engine, a package mirror — is exactly what stops working. Inactive profiles arm no window, because writing to them cannot break anything, and joining a Wi-Fi network arms none either: a failed join leaves the previous profile intact and selectable.

Settings

Setting	Type	Default	Description
confirm_seconds	int	45	How long to wait for confirmation after a change before the previous settings are restored. 0 writes immediately, with no window.
refresh_seconds	int	15	How often the stored profile, the live addresses, the scan age and the radio state are re-read.
show_text	bool	true	Bar widget shows the network name next to the glyph.
glyph	glyph	network	Bar widget icon when no interface is up.

IPC

Every action is reachable without the panel, which is also how the tests drive it. all is the required target for a service entry.

ID=muhammadessam/network-control:service

# read
noctalia msg plugin $ID all request '{"action":"refresh"}'
noctalia msg plugin $ID all request '{"action":"diagnose"}'

# Wi-Fi
noctalia msg plugin $ID all request '{"action":"scan"}'
noctalia msg plugin $ID all request '{"action":"wifi-connect","ssid":"MyNetwork","password":"secret123"}'
noctalia msg plugin $ID all request '{"action":"wifi-connect","ssid":"Hidden","password":"secret123","hidden":true}'

# addressing
noctalia msg plugin $ID all request '{"action":"select","uuid":"<uuid>"}'
noctalia msg plugin $ID all request '{"action":"apply","uuid":"<uuid>","form":{"ipv4_method":"manual","ipv4_addresses":"10.0.0.5/24"}}'
noctalia msg plugin $ID all request '{"action":"keep"}'
noctalia msg plugin $ID all request '{"action":"revert"}'
noctalia msg plugin $ID all request '{"action":"restore"}'

# connection and radio
noctalia msg plugin $ID all request '{"action":"up","uuid":"<uuid>"}'
noctalia msg plugin $ID all request '{"action":"down","uuid":"<uuid>"}'
noctalia msg plugin $ID all request '{"action":"radio","kind":"wifi","on":true}'

apply takes a partial form; omitted fields count as empty. Both ipv4_method and ipv6_method must be a supported method, so an IPv4-only change still states its IPv6 method.

diagnose writes the service's whole view (connections, profile, live addresses, primary route, permissions, scan result, pending window, restore point) to ~/.local/state/noctalia/plugins/data/muhammadessam/network-control/state.json and logs a one-line summary. That is the file to look at when the panel and nmcli disagree.

Notes

• Profiles written: nmcli con mod <uuid> for the fields that changed, then nmcli con up <uuid> when the connection is active. Joining a secured network creates one Wi-Fi profile (nmcli con add, no secret in the argument list) — and deletes it again if the join fails, so a network that did not work is never left looking saved.
• Files written, all in the plugin's data directory: last-profile.json (the restore point, written before the connection is modified so a failure in between still leaves something to recover from) and secret.tmp (a Wi-Fi passphrase — nmcli con up --passwd-file reads it instead of taking a secret as an argument, because a command line is world-readable in /proc while a stored NetworkManager key is root-only). secret.tmp is created empty and 0600 by install -m 600 before the secret is written into it, removed on every path out including failures, and any file left by a shell that died mid-join is removed at startup. If it cannot be created privately the join fails rather than activating without the passphrase. state.json is diagnose output only.
• Passphrases and SSIDs are byte-exact: neither is trimmed, because leading and trailing spaces are legal in both. Only an all-space manual entry is rejected.
• Commands spawned: nmcli -t -f … con show, nmcli -t -f … dev status, nmcli -t -f … dev show <dev>, nmcli -t -f … dev wifi list [--rescan yes], nmcli radio, nmcli -t general permissions, nmcli con mod, nmcli con add, nmcli con up|down, nmcli con delete (only a profile this plugin just created), ip -j route get 1.1.1.1, plus install -m 600 and chmod 600 for the passphrase file.
• Network access: none of its own. It reads and writes NetworkManager only.
• Secrets: a passphrase typed into the panel travels through the plugin's in-process request channel to nmcli and nowhere else. It is never written to plugin state, never logged, and never part of the diagnose dump.
• Reading the live state: the plugin reports the interface from ip route get, not the first entry in the routing table. A stray static route on a dummy link (metric 550 against Wi-Fi's 600) wins the table but is not where traffic goes.
• DNS with DHCP: DNS servers and search domains are stored on the profile and apply to every method, so a static DNS list survives a switch back to DHCP.
• Compositor-agnostic: nothing here talks to the compositor.
• While a confirmation window is open the service refuses every other mutation (join, up/down, radio, restore) instead of racing the rollback timer.
• Not implemented, deliberately: creating or deleting profiles from the panel, Wi-Fi secrets other than a WPA/SAE passphrase (802.1X identities and certificates, WEP), shared/hotspot mode, per-route tables, MAC cloning, and VPN or WireGuard profile internals. The IPv6 method does include Ignore, the usual answer for a connection whose IPv6 is handled elsewhere.

Tests

lua tests/run.lua                    # assertions against net.luau, no host needed
sh tests/capture-fixtures.sh         # re-capture nmcli fixtures from this machine
python3 tests/check-translations.py  # every tr() key exists in en.json
python3 tests/e2e-live.py            # live end-to-end, needs the running shell
lua tests/secret-path.lua            # the passphrase path, no shell and no NetworkManager
python3 tests/make-thumbnail.py      # rebuild thumbnail.webp from the official generator

tests/e2e-live.py creates one throwaway dummy connection (no gateway, so it cannot displace the default route) and deletes it again. It drives the plugin's IPC surface only, and covers validation refusals, a real write, the keep path, the timeout rollback and the restore action. It never touches an existing profile.
