KWallet Secrets

NetworkManager keeps no copy of an agent-owned Wi-Fi password, and no copy of a VPN password at all: it asks a registered secret agent for them every time you connect. On a Plasma desktop that agent is plasma-nm, which reads them out of KWallet. On a Noctalia session there is no such agent, so every one of those networks and every VPN asks you to type a password you already saved. This plugin fills that gap: it runs a secret agent that answers NetworkManager out of KWallet, so they just connect.

Plugin

Field	Value
ID	grassyloki/kwallet-secrets
Entries	service: service

Requirements

• python3, with the python-dbus and python-gobject bindings. Both ship as distro packages (python-dbus / python3-dbus, python-gobject / python3-gi); no pip install and no virtualenv is involved.
• kwalletd6, the classic KWallet daemon. It provides the org.kde.KWallet D-Bus interface this plugin reads. The newer ksecretd serves the same wallet file over the Secret Service API but does not implement that interface, so it is not a substitute.
• pkill (from procps-ng) and systemd-cat (from systemd), used to supervise the helper process and to route its output to the journal.
• NetworkManager as the network stack, and a KWallet wallet that is unlocked. kwallet-pam unlocks it at login; without it, the first lookup of the session raises KWallet's unlock dialog.

The plugin is compositor-agnostic: nothing in it depends on Hyprland, niri, or any particular Wayland session.

Usage

There is nothing to add to your bar and no panel to open. Enable the plugin and the service starts a background secret agent; from then on, saved Wi-Fi networks and VPNs whose passwords live in KWallet connect without prompting.

To check that it is working:

journalctl -b -t NetworkManager | grep 'agent registered'
journalctl --user -t noctalia-kwallet-secrets -f

The first command should list an agent named io.github.grassyloki.kwalletSecrets. The second follows the plugin's own log, which prints one line per request: a hit when the password came from the wallet, a miss when the wallet had no entry for that network.

To see what the wallet actually holds, run the helper directly. It prints entry and key names only, never a password:

~/.local/state/noctalia/plugins/materialized/community/kwallet-secrets/scripts/kwallet-nm-agent.py \
  --check --with-vpn --with-8021x

If a network or VPN still prompts, the usual causes are a locked wallet, a profile whose password was never saved to KWallet in the first place, or a stored password that is simply wrong — see Notes.

Settings

Configure these under Settings, Plugins, KWallet Secrets. Changing any of them restarts the helper.

Setting	Type	Default	Description
wallet_name	string	(empty)	Wallet to read. Empty means whichever wallet KWallet has configured for network data, normally kdewallet.
folder_name	string	Network Management	Folder inside the wallet holding the entries. This is where plasma-nm puts them; change it only if you keep them somewhere else.
app_id	string	Noctalia KWallet Secrets	The name KWallet shows when it asks whether to grant access to the wallet.
handle_8021x	bool	false	Also answer 802-1x requests, for WPA-Enterprise networks such as eduroam. Off by default because those profiles often carry certificates that no wallet entry covers.
handle_vpn	bool	true	Also answer vpn requests — OpenVPN, vpnc, openconnect, L2TP and the rest — and NetworkManager's own wireguard setting, including per-peer preshared keys. On by default, because a VPN secret is agent-owned in every profile plasma-nm imports and so prompts on every single connect.
unlock_prompt	bool	true	Allow KWallet to raise its unlock dialog when the wallet is locked. Turn this off to treat a locked wallet as "no password" instead, so connecting fails quietly rather than popping a dialog.
debug_logging	bool	false	Log every request, including the ones deliberately declined. Passwords are never logged at any level.

How it works

The problem

Every saved Wi-Fi profile in NetworkManager marks its password with a secret flag. psk-flags=0 means NetworkManager stores the password itself, in /etc/NetworkManager/system-connections, and any client can connect. psk-flags=1 means agent-owned: NetworkManager deliberately keeps no copy and asks a registered secret agent at connect time. plasma-nm sets that flag on everything it saves, so a machine that used to run Plasma typically has a large pile of agent-owned profiles whose passwords live only in KWallet, under a folder called Network Management, keyed {uuid};802-11-wireless-security.

VPN profiles are worse off still: NetworkManager never stores a VPN secret itself, so a VPN password is agent-owned whatever the flags say. plasma-nm keeps those in the same folder, keyed {uuid};vpn.

Noctalia registers its own secret agent, but that agent has no persistent store — all it can do is prompt. So on a Noctalia session those profiles ask for a password on every connect, even though the password is sitting in the wallet.

The fix

scripts/kwallet-nm-agent.py is a small daemon that registers on the system bus as a second NetworkManager secret agent, under the identifier io.github.grassyloki.kwalletSecrets. It implements the three calls NetworkManager makes on an agent:

• GetSecrets — looks up {uuid};<setting> in the wallet folder and returns the keys it finds. On a miss it answers with the NoSecrets error, which is NetworkManager's cue to ask the next agent in line. That is what keeps Noctalia's prompt working as the fallback for a network the wallet has never seen: this plugin adds a path, it does not take one away.
• SaveSecrets — writes the password into the wallet when a profile is added or changed, so a password you type once ends up in the same store the plugin reads from.
• DeleteSecrets — removes the wallet entry when the profile is deleted, so the wallet does not accumulate orphans.

VPN secrets are shaped differently

Two things about the vpn setting do not look like any other setting, and the plugin special-cases both.

On the NetworkManager side, a reply for vpn nests its secrets one level deeper: {"vpn": {"secrets": {"password": "..."}}}, where the inner map is a{ss}, not the a{sv} every other setting uses. That is what libnm itself emits and what plasma-nm sends, so it is the shape the plugin sends. (Modern NetworkManager is lenient and will also fold flat top-level string entries into the VPN secrets, but the nested form is the documented one.) The same asymmetry applies when NetworkManager hands a connection back on a save: the vpn setting arrives split into data and secrets, and only the latter holds passwords.

On the KWallet side, the entry is not one map key per secret. NetworkManagerQt flattens the entire VPN secret map into a single VpnSecrets key whose value is key, separator, value, separator, key, … joined by the literal %SEP%. The plugin packs and unpacks that format, so --check still lists real key names and a password saved here is one plasma-nm can read.

Which secrets a VPN uses depends on the VPN plugin — openvpn has password, cert-pass and http-proxy-password, vpnc has Xauth password, openconnect has a cookie — so unlike Wi-Fi there is no fixed list of key names to filter against. Whatever non-empty keys the wallet holds are returned, and whatever non-empty keys NetworkManager sends are saved. NetworkManager passes hints naming the one secret it is after; the plugin logs them and returns everything it found anyway, exactly as plasma-nm does, because a VPN plugin routinely needs a second secret that the hint never mentions.

wireguard rides along under the same setting. NetworkManager's native WireGuard is not the vpn setting at all — it is its own setting, with an agent-owned private-key and an agent-owned preshared-key per peer — but it is a VPN to the user, and plasma-nm keys it {uuid};wireguard. Its reply is the ordinary flat shape for private-key. A peer's preshared key needs one more step: the wallet keys it peers.<public-key>.preshared-key, but sending it back under that flat name makes NetworkManager reject the whole answer with secret not found. It has to travel inside the setting's peers array instead, next to the public key that says which peer it belongs to, which is what the plugin builds from the peer list NetworkManager passes in with the request.

Other details

Two details matter for behaviour you will actually notice. When NetworkManager sets the REQUEST_NEW flag it is telling the agent that the stored password was just rejected; the plugin answers NoSecrets there rather than handing back the same wrong password, so a changed Wi-Fi or VPN password produces a prompt instead of a retry loop. And every KWallet call is given a deadline (15 seconds by default). kwalletd6 can wedge — it has been seen stuck in futex_wait, hanging every open() — and a stuck wallet has to degrade to "no password" rather than freezing the connection attempt.

Reading the wallet

KWallet stores these entries as maps, which on the wire are a raw Qt QDataStream dump of a QMap of strings: a big-endian count, then alternating keys and values, each a byte length followed by UTF-16 big-endian text. The helper encodes and decodes that format directly, which is why it needs no KDE or Qt bindings — just D-Bus and a main loop.

Supervision

service.luau does no secret handling at all. It starts the helper under systemd-cat, so the helper's output lands in the journal under the tag noctalia-kwallet-secrets instead of a private log file, and re-checks every 30 seconds that it is still alive. "Alive" is decided by looking for the helper's single-instance lock, an abstract unix socket, in /proc/net/unix; the helper takes that lock at startup and a duplicate copy exits immediately, so no combination of restarts can end up with two agents fighting over the same identifier.

A launch is confirmed the same way. The helper is started in the background, so the launching shell exits successfully whatever happens to it — a missing systemd-cat would look exactly like a clean start. Rather than trust that, the service waits for the lock to appear and only then reports the agent as running; if it never appears the service says so, logs it, and tries again on the next check. The four commands the plugin depends on are verified before any of this, and a missing one disables the plugin with a message naming it rather than failing quietly.

Notes

• Processes spawned. One long-lived python3 process per session. Around it the service runs only short-lived shell commands: grep against /proc/net/unix and id -u to check whether the helper is up, setsid plus systemd-cat to launch it, and pkill to stop it when a setting changes. grep, id, and setsid are not declared as dependencies because they come with coreutils and util-linux on every supported system.

• Network access. None. The helper talks to two D-Bus buses and nothing else: NetworkManager on the system bus, KWallet on the session bus.

• Files written. None. The plugin writes no state of its own; the only thing it ever changes is wallet content, and only through KWallet's own API in response to a NetworkManager save or delete.

• Passwords are never logged. Log lines record the profile name, its UUID, the setting, and which key names were found — never a value. --check obeys the same rule.

• This does not migrate anything. Profiles that already store their password in NetworkManager keep doing that. If you would rather stop depending on the wallet for one network, nmcli connection modify UUID 802-11-wireless-security.psk-flags 0 together with the password moves it into NetworkManager's own store.

• Running it by hand. The helper lives at ~/.local/state/noctalia/plugins/materialized/community/kwallet-secrets/scripts/kwallet-nm-agent.py once the plugin is installed, and --help lists every flag. Stop the supervised copy first, since a second instance exits immediately on its lock:

  cd ~/.local/state/noctalia/plugins/materialized/community/kwallet-secrets
  pkill -f 'kwallet-nm-agent[.]py'
  ./scripts/kwallet-nm-agent.py --debug


  The service starts its own copy again within 30 seconds of the manual run ending.
