Key Visualizer

A minimal, real-time floating on-screen keystroke visualizer HUD for Noctalia. Displays typed keys and modifier combinations as translucent, blurred glass keycaps directly on your screen.

Plugin

Field	Value
ID	h-jangra/keyviz
Entries	Bar widget: widget; panel: overlay; shortcut: toggle; service: keylistener

Requirements

• python3 on PATH (used by the background event listener service).
• Linux user in the input group to read /dev/input/event* devices:

  sudo usermod -a -G input $USER


  (Note: Log out and log back in for group membership to take effect).

Usage

Panel

Toggle the key visualizer overlay HUD directly via IPC:

noctalia msg panel-toggle h-jangra/keyviz:overlay

Bar Widget & Shortcut

• Bar Widget (widget): Add h-jangra/keyviz:widget to your bar items in Noctalia settings to get a quick visual status icon and toggle button.
• Control Center Shortcut (toggle): Add h-jangra/keyviz:toggle to your control center shortcuts to pause or resume key visualization.

IPC Commands

Control the listener service dynamically:

# Toggle key visualizer on/off
noctalia msg plugin h-jangra/keyviz:keylistener all toggle

# Clear currently displayed keys
noctalia msg plugin h-jangra/keyviz:keylistener all clear

Settings

Configure Keyviz in Noctalia Settings → Plugins → Key Visualizer:

Setting	Type	Default	Description
enabled_by_default	bool	true	Start visualizer automatically when Noctalia starts.
padding	int	6	Internal padding spacing inside overlay around keycaps (0 – 30).
margin	int	6	Spacing gap between visualized key combinations (0 – 30).
timeout_ms	int	500	Inactivity duration (ms) before keys disappear (200 – 5000).
max_keys	int	4	Maximum number of key combinations to display (1 – 8).
font_size	select	medium	Text size of keycaps (small, medium, large).
badge_style	select	glass	Visual style (glass, solid, accent).
show_modifiers_only	bool	false	Only visualize combinations with Ctrl, Alt, Shift, or Super.

License

MIT
