Keyboard State

Displays the current state of the Caps Lock, Num Lock, and Scroll Lock keys in the Noctalia bar. The plugin monitors keyboard LED events and keeps the displayed states synchronized with the keyboard. Individual lock keys can be shown or hidden, inactive indicators can be hidden, and the glyph, color, and spacing can be customized.

Plugin

Field	Value
ID	ismay/keyboard-state
Entries	Bar widget: keyboard-state; service: service

Usage

Add the keyboard-state widget to your Noctalia bar. Configure the input device path to monitor in the plugin settings. Use evtest in the terminal to find the correct device path. Use stable paths from /dev/input/by-id/ or /dev/input/by-path/ when possible, because /dev/input/eventN names can change after device or kernel updates. Then customize which lock keys are displayed and how they appear in the widget settings.

Requirements

Requires permission to read the configured input device. On many systems, this means adding your user to the input group and logging out and in again. The configured input device must be an existing device under one of these paths:

• /dev/input/event*
• /dev/input/by-id/*
• /dev/input/by-path/*

Requires both evsieve and evtest to be available on PATH.

• evsieve monitors keyboard LED state changes.
• evtest queries the initial state of each lock key.

Although evtest can also monitor LED state changes, doing so can modify the keyboard's LED state. evsieve is therefore used for continuous monitoring.

Settings

Setting	Type	Default	Description
input_device	file	""	Path to the input device to monitor for keyboard lock key events.
hide_inactive	bool	false	Hide lock key indicators when they are inactive.
active_color	color	"primary"	Color used when a lock key is active.
inactive_color	color	"on_surface"	Color used when a lock key is inactive.
icon_spacing	int	4	Spacing between lock key icons in pixels.
show_caps_lock	bool	true	Show the Caps Lock indicator.
caps_lock_glyph	glyph	"square-letter-a-filled"	Glyph displayed for Caps Lock.
show_num_lock	bool	true	Show the Num Lock indicator.
num_lock_glyph	glyph	"square-number-1-filled"	Glyph displayed for Num Lock.
show_scroll_lock	bool	true	Show the Scroll Lock indicator.
scroll_lock_glyph	glyph	"square-arrow-down-filled"	Glyph displayed for Scroll Lock.

Notes

• The widget is hidden when the service encounters an error.
• The widget is also hidden when all lock key indicators are disabled or hidden due to their current state.
• Errors are logged to the Noctalia log.
