Herdr

Monitor Herdr sessions and coding agents from Noctalia, with attention state in the bar and an attached popup panel.

Plugin

Field	Value
ID	hy4ri/herdr
Entries	Bar widget: bar; panel: panel; service: service

The service entry owns every Herdr command and publishes one normalized herdr.state snapshot. The bar and panel entries only render that shared state and send action requests back to the service.

Requirements

Install this on PATH (declared in plugin.toml dependencies):

• herdr — session discovery, snapshots, agent focus, and session lifecycle actions.

Optional, for focusing existing terminal windows:

• hyprctl — focuses an already-open Herdr terminal window on Hyprland.
• niri — lists and focuses windows on Niri, and provides the window picker when needed.
• ps — maps attached Herdr client processes to terminal windows through /proc/PID/stat.

Hyprland integration uses hyprctl and ps. Niri integration uses niri and ps, and requires Noctalia to inherit NIRI_SOCKET from the compositor session. These compositor-specific tools are optional rather than mandatory manifest dependencies. On other desktops the plugin opens or attaches to a session through Noctalia's configured terminal. On Niri, discovery or focus errors are reported without opening a duplicate terminal.

Usage

Add the hy4ri/herdr:bar widget to a Noctalia bar. The number beside the robot icon is the count of agents that are done or need action (blocked + done). Its attention color follows this order: Needs you, Done, Working, then Ready.

Click the widget to open the panel anchored next to the bar. A running session is listed as its workspaces. A workspace holding more than one pane is named once, with its panes underneath it, so a workspace running two agents no longer reads as two unrelated rows. A workspace holding a single pane stays a single row named by the workspace, with that pane's title underneath and nothing nested below it. Workspaces are ordered by attention state, and the panes inside one are ordered the same way. Use the panel to:

• open or start a session;
• focus an agent pane;
• stop a running session;
• delete a stopped named session after confirmation;
• refresh immediately.

The default session can be stopped and started, but cannot be deleted.

Refresh stays focusable during background polling. Clicking it while a refresh is already running does not queue another refresh.

Opening a session or focusing an agent closes the popup before switching windows on both Niri and Hyprland.

noctalia msg panel-toggle hy4ri/herdr:panel

Settings

Bar widget settings — Settings → Bar → the Herdr widget:

Setting	Type	Default	Description
display_mode	select	icon_and_count	Choose what to display on the bar widget (icon or icon_and_count).
hide_count_when_zero	bool	true	Hide the badge count when no agents need action or are done, showing only the icon.
color_blocked	color	error	Color used for agents needing action, in the bar badge and the panel.
color_done	color	tertiary	Color used for agents that completed their tasks, in the bar badge and the panel.
color_working	color	primary	Color used for active running agents, in the bar badge and the panel.
hide_agentless_panes	bool	true	Hide panes that are running no agent, so the panel lists agents only.

Plugin settings — Settings → Plugins → Herdr:

Setting	Type	Default	Description
show_other_machines	bool	false	Also list the other machines saved in Herdr (herdr machine list) at the end of the panel while it is open.

Why the colors and the pane filter live on the widget

Noctalia seeds an entry runtime with the settings that entry declares plus the plugin-level ones — never another entry's. A [[widget.setting]] is therefore readable by that widget alone: the panel and the service would get nil and Noctalia would log an undeclared-setting miss on every read.

So the widget owns those four values, and republishes them into shared plugin state (herdr.settings) when it loads and whenever they change. The panel reads its colors from there and the service reads the pane filter from there, which keeps one settings surface for display options while the panel and the service still see the same values. Two consequences worth knowing:

• The values are stored per widget instance. With a single Herdr widget this is invisible; with several, the last one to publish wins.
• With no Herdr widget on a bar, nothing publishes them and the panel and the service use the built-in defaults.

Other machines

With show_other_machines enabled, every enabled machine from herdr machine list is read through herdr --machine <id> api snapshot and shown after the local sessions. Only the socket API is available on a remote machine, so those rows are read-only: they list panes and agent states, and they cannot be stopped, deleted, or focused from this panel.

Remote rows are polled only while the panel is open and at most once every 15 seconds, because each read crosses SSH.

Once a machine has been read, its agents count toward the bar badge, the tooltip, and the panel summary alongside your local ones — so an agent waiting on another machine still turns the widget red. Each machine counts as one running session in that rollup. A machine that cannot be reached keeps its last known counts, is marked stale, and stays marked until it answers again.

Agent states

The plugin uses Herdr's semantic agent status directly:

Herdr state	Display
blocked	Needs you
done	Done
working	Working
idle	Ready
unknown	Unknown
no agent	No agent

Within the same state, agents that changed state more recently are shown first using Herdr's state_change_seq.

Panes with no agent (a plain shell, an editor, a TUI) report No agent and are hidden by default. Turn hide_agentless_panes off to list them under their workspace next to the agent panes. Either way they are excluded from the session counts, the bar badge, and its attention color, so the rollup stays agent-based, and a workspace with nothing to show is left out entirely.

Whether a workspace nests its panes follows the workspace's real pane count, not how many panes survive that filter: a workspace with two panes keeps its shape while hide_agentless_panes is on and simply lists the panes it shows.

A pane's row title is taken from its agent name, terminal title, or working directory. A pane whose working directory has no basename (a pane sitting at /) shows the path itself rather than a raw HerdR pane id. A workspace row is named by the workspace's label, falling back to its first pane's tab or title when the workspace has no label.

Refresh cadence

Herdr exposes no event stream over its socket API, so the widget cannot be pushed to: the service polls, and the widget is only as fresh as that poll. The ladder is:

State	Interval
The panel is open	1000 ms
An agent is blocked or done	1500 ms
An agent is working	1500 ms
Everything idle	5000 ms

A refresh is herdr session list --json plus one herdr api snapshot per running session, both local socket calls, so a fast cadence stays cheap. Refreshes never stack: a tick that lands while one is in flight is collapsed into a single follow-up read. The cadence slows on its own as soon as nothing needs attention.

Hyprland integration

When hyprctl and ps are available, the service maps Herdr client processes to hyprctl clients -j results. Opening a mapped session focuses its existing window. Focusing an agent first runs Herdr's agent focus command, then brings that session window forward.

If the session has no mapped window, or compositor focusing is unavailable, the service uses noctalia.runInTerminal with herdr for the default session or herdr --session NAME for a named session.

Client-process discovery on both Hyprland and Niri accepts bare herdr and herdr attach, including --session NAME, --session=NAME, and --handoff, plus herdr session attach NAME. Short-lived commands such as herdr api, herdr agent focus, herdr status and herdr server do not count as attached clients; neither do --remote clients. This also narrows the Hyprland process matching compared with earlier plugin versions.

Niri integration

When Noctalia runs inside Niri, the service matches niri msg --json windows results to attached Herdr clients by their parent processes. Clicking an agent first focuses its Herdr pane, then brings the existing terminal forward with niri msg action focus-window --id ID. The window list is checked again on every click. A terminal is opened only when no window is mapped to that session.

Within those process-matched candidates, a unique title match skips the picker. The service recognizes Herdr 0.9.5's default {hostname}: {workspace} title using the local hostname (/proc/sys/kernel/hostname) and workspace labels it already polls. It also recognizes titles beginning with herdr (case-insensitive), such as Herdr: project. If several sessions share a terminal process, a title must distinguish the requested session by its workspace or an explicit session name; session names use exact case and whole-name boundaries. A generic herdr title alone cannot distinguish those sessions. Editor titles and unrelated process windows are not treated as matches.

Title matching does not change Herdr's configuration or terminal titles and makes no extra Herdr calls. The default title needs no configuration change. A custom title can retain a recognizable prefix, for example window_title = "herdr: {hostname}: {workspace}" under [ui] in Herdr's config. See Herdr's title configuration for supported tokens; Herdr 0.9.5 has no {session} token.

Some terminals, including Ghostty, can have several windows sharing one process. If multiple candidates remain and no title uniquely identifies the window, Niri's window picker opens: click the existing Herdr terminal once, or press Escape to cancel. A Noctalia notification names the session and asks you to select its existing terminal window, with an Esc cancellation hint. An existing remembered choice takes precedence over title matching while it remains valid. Automatic title matches are checked afresh on every click. The manual choice is kept in memory for that session and checked against all attached clients on subsequent clicks. Background polls never clear it; a successful click-time discovery discards it when it no longer matches. Restarting Noctalia or disabling the plugin clears the choice, so an ambiguous session needs the picker again afterward. Window IDs and selections are not written to disk.

The popup closes before selection so it does not cover the target window. Cancelling the picker is silent, and repeated clicks do not start competing pickers. Selecting an unrelated window shows a hint; command failures are reported and logged with the HerdR Niri picker: prefix. Neither case creates an extra terminal.

While a focus or picker request is pending, only further open/focus requests are blocked. Refresh, stop and delete requests remain available, and their completion does not release the pending focus request's lock. A cancelled picker leaves no error banner in the panel.

Development tests

Run from the repository root with Lua 5.4 or newer and Python 3:

lua herdr/tests/test_focus.lua
noctalia plugins lint herdr

The tests load the real service and panel scripts against mocked process and compositor APIs. They cover default and named sessions, shared terminal processes, multiple clients, selection cancellation/revalidation, overlapping requests, command failures, and the existing Hyprland focus path. Regression cases exercise the actual command watcher during a pending picker, stop/delete completion and failure, incomplete background polls, click-time invalidation, and cancelled status rendering. Title cases cover default and prefixed titles, named sessions sharing a process, duplicate workspace labels, exact session-name boundaries, unrelated titles/windows, remembered choices and title changes between clicks. Notification cases check the session name, cancellation hint, prompt-before-picker ordering, and that direct focus, remembered choices and rapid clicks do not emit unnecessary or duplicate prompts.

The panel regression also checks that Refresh stays enabled with a stable control key during polling, ignores busy clicks and accepts clicks after polling finishes.

Representative Niri JSON fixtures also pass through Python's standard JSON parser at the mocked noctalia.json.decode boundary, covering window arrays, picked-window objects, nullable fields, malformed JSON and cancellation. Python is only a test dependency; the plugin continues to use Noctalia's built-in JSON decoder, which this offline harness does not execute. These tests do not replace a live desktop test.

Notes

• Running state comes from herdr session list --json.
• Each running session is read through herdr api snapshot.
• Stopped-session project names come from that session's saved session.json.
• One failed session snapshot is kept as a stale/degraded row while other sessions continue updating.
• Polling follows the ladder in Refresh cadence.
