Containers

Noctalia bar widget + panel that shows your Docker and Podman containers and the services running directly on your machine, and opens the ones with a web UI straight in your browser.

Plugin

Field	Value
ID	davinci13/containers
Entries	Bar widget: bar, Panel: panel, Shortcut: shortcut, Service: service

Usage

1. Open Noctalia Settings.
2. Go to Bar, add a widget, and select Containers (davinci13/containers:bar).
3. Optionally add the tile in Control Center (davinci13/containers:shortcut).
4. Click the bar widget or control-center tile to open the panel, or toggle it via IPC:

   noctalia msg panel-toggle davinci13/containers:panel


What it does

• Discovers containers from both runtimes every few seconds. A missing docker or podman binary is reported as not installed in the panel rather than breaking the plugin — either runtime on its own is enough.
• Also lists host services: your own listening TCP ports, one row per process, named after its systemd unit when there is one.
• Shows a web UIs / total counter on the bar and the same count as a control-center tile.
• Lists every container grouped by runtime, with its image, live status, and its published ports. Containers with no published port are shown too, but they are not clickable.
• Click a container to open its first published port. Click a port chip to open that specific port. Right click a chip to copy the URL.
• Newest data always comes from the service, so the panel is never stale.

The panel

• Compact rows. Each service is two lines: name plus port chips, then the image/description plus its status. Padding is 6 px and the chips are sm, so a typical row is ~34 px tall.
• Separated by source. Every runtime gets its own band — a filled, outlined header with its glyph, name and count — and a rule sits between two of them, so Docker, Podman and Host never read as one list. Running rows are solid surface_variant, stopped ones are outlined, so the state stays visible without a translucent fill.
• Scrolls. The declared height is a viewport, not a cap: the list takes the free space between the header and the footer (flexGrow) and scrolls inside it, so fifty services cost you a scrollbar, not a broken panel.

Host services

One ss probe finds the listening sockets and systemd names the ones it owns:

Socket	Row
LISTEN … 0.0.0.0:4321 … users:(("MainThread",pid=85882)) with MainPID=85882 on nginx.service	nginx — A high performance web server
LISTEN … 127.0.0.1:18000 … users:(("ssh",pid=52931)) with no unit	ssh — pid 52931
LISTEN … 0.0.0.0:51911 … six times on six addresses	one qbittorrent row with a single port chip

• One row per process, not per socket, so a service bound to 0.0.0.0, 127.0.0.1, 192.168.1.4 and [::1] is one row with one chip per port.
• Names come from the unit (.service dropped) and the description goes on the second line; without a unit the process name and its pid are used instead.
• Skipped: sockets you cannot see the owner of (another user's), link-local addresses, and the runtime helpers (docker-proxy, conmon, …) that only forward a port the container list already has.
• Only TCP is listed, because only TCP can serve a web UI.

Non-root ss cannot see which process owns another user's socket, so systemd-resolved or cups stay hidden until you set Command prefix to sudo -n. That prefix applies to every lookup the plugin runs.

Install

Drop this directory into your Noctalia plugin data dir and enable it:

cp -r containers ~/.local/share/noctalia/plugins/
noctalia msg plugins enable davinci13/containers     # note: needs WAYLAND_DISPLAY set
noctalia msg plugins list                           # -> davinci13/containers [local] 1.2.0 enabled

Then add the widget to a bar in Settings → Bar (look for davinci13/containers:bar), and the tile in Settings → Control Center (davinci13/containers:shortcut). The plugin is not usable from the launcher until the widget is placed — the panel is opened by the widget or the tile.

Editing

• .luau edits hot-reload on save; the file watcher reloads the owning entry.
• translations/*.json is read when the plugin loads, so cycle the plugin after changing one: noctalia msg plugins disable davinci13/containers then enable. Skipping the cycle makes noctalia.tr(key) warn plugin translation key ... not found while still returning the key.

For development, point a path source at your working copy instead — the data-dir copy above always wins over sources, so edit in place there for iteration:

noctalia msg plugins source add local-dev path ~/Projects/noctalia_container_services/containers

Settings

Setting	Default	Notes
Refresh interval	5 s	Seconds between lookups.
Include stopped containers	off	Adds -a, so exited containers show up too.
Include host services	on	Also lists your own services listening on a TCP port.
Host used for links	localhost	Used when a port is published on every interface (0.0.0.0, ::, empty) or bound to loopback. Ports bound to a specific address keep that address — 192.168.1.50:3000 links to 192.168.1.50.
Command prefix	empty	Runs every lookup as-is. Set sudo -n if your user has no daemon socket, or to let ss see other users' ports.
Browser command	empty	Empty uses xdg-open, i.e. your default browser.

The bar widget also has its own icon, counter toggle, and hide-when-empty toggle under Settings → Bar → the widget.

How links are built

Published as	Link
127.0.0.1:8888->8888/tcp	http://localhost:8888
0.0.0.0:8080->80/tcp	http://localhost:8080
0.0.0.0:443->443/tcp	https://localhost:443
:::9090->9090/tcp, [::]:9090->9090/tcp	http://localhost:9090
192.168.1.50:3000->3000/tcp	http://192.168.1.50:3000
host socket *:8080 or 127.0.0.1:8080	http://localhost:8080

Only TCP is offered — a UDP-only publish cannot serve a web UI. Published port ranges (8000-8005->80/tcp) are expanded and each port is its own chip, capped at 64 to keep the state message small. HTTPS is only assumed on port 443; anything else that speaks TLS opens as http://, so let your browser retry.

Container-only ports

A container can listen on a port it never publishes. surrealdb-local here publishes nothing, so docker ps shows an empty Ports column — yet it serves SurrealDB on 0.0.0.0:8000 inside its own network namespace, reachable from the host on its bridge IP.

Those ports are found by reading the container's /proc/<pid>/net/tcp for listening sockets and pairing each with the container IP from docker inspect. Only wildcard binds count: a 127.0.0.1 bind inside the namespace is not reachable from the host.

	Published	Container-only
Link	http://localhost:8888	http://172.17.0.2:8000
Chip style	filled	outlined
Tooltip	the URL	the URL + "inside the container"

They are shown after a real published port, never instead of one, so a container that publishes 8888 keeps its localhost link. If you would rather not have these probed at all, disable host services — the probe runs with the same command_prefix as the rest of your lookups.

Layout

plugin.toml          manifest: identity, settings schema, four entries
service.luau         headless discovery: docker, podman and host ports, publishes "snapshot"
widget.luau          bar tile: counter, click opens the panel, right click refreshes
panel.luau           the list; every click opens or copies a URL
shortcut.luau        control-center tile, same count and toggle
translations/en.json settings labels and every UI string

Only the service talks to docker, podman, ss and systemctl; the other entries read the snapshot it publishes through noctalia.state, so nothing is parsed twice and no two entries can disagree.

Development

update() in the service ticks once a second and refreshes on the interval above. A refresh in flight makes the next one a no-op, so a slow daemon cannot pile up processes. Force one from the shell:

noctalia msg plugin davinci13/containers:service all refresh
noctalia msg panel-toggle davinci13/containers:panel

Requirements

External command dependencies declared in plugin.toml:

Container Runtimes (Optional)

• docker: Optional container runtime CLI (requires a reachable daemon for your user). When installed, running and stopped Docker containers are listed.
• podman: Optional container runtime CLI. When installed, Podman containers are listed.

Host Service Discovery (Optional)

• ss: Optional socket statistics tool (from iproute2), used to discover listening TCP services on the host when host service discovery is enabled.
• systemctl: Optional service manager CLI (systemd), used to enrich host service entries with unit names and descriptions. When unavailable, host services fall back to process names and PIDs.

Internal Container Port Discovery

• awk: Used by the internal port probe to inspect /proc/$pid/net/tcp and /proc/$pid/net/tcp6. Requires GNU awk (gawk) with strtonum support to decode hexadecimal socket ports.
• cut: Used by the internal container probe pipeline to parse container inspect fields.

URL Launching

• xdg-open: Default tool used to open container and host URLs in your web browser. Can be overridden with the browser_command setting.
